Split AC Conditioner Parts and Functions

The whole assembling process of the Split air conditioning system can be divided into two components, the indoor side component and the outdoor side component. The indoor and the outdoor components are separated from each other completely and are connected to each other by the refrigerant piping and electric communication wiring.

The indoor unit consists of the parts such as:

Air Filters: Useful to filter the indoor air and remove dust particles and bacteria from it.

Cooling Coil: It is the area where the heat exchange happens between the refrigerant and the room air.

Fan Blower: It is used to discharge the cool air into the room.

Display Panel: It consists of electronic sensors of the remote control to control the speed of the fan blower and the temperature and some other fuzzy functions. Like timer, air sweep, air swing, etc.

Drain pan: This is used to hold the water that condensate from the cooling coil which is then discharged out by gravity.

The outdoor unit consists of the parts such as:

Compressor: This is used to compress the refrigerant.

Condenser Coil: The condenser coil is used to reject the heat from refrigeration to the outdoor air.

Capillary Tube: It is used as an expansion device

Filter drier: This is used to remove the moisture from the refrigerant.

Propeller Fan and Motor: It is used to move the air molecules to the surface of the condensing coil and expel heat from the condenser in the atmosphere.

Details about Split AC Conditioner Working

• Once the room temperature reaches the set point of thermostat it turns on the compressor of split air conditioner. This draws the room air through the air inlet grill where the filter removes the dust particles.

•Immediately, the refrigerant is pumped through tubing which initiates the process of refrigeration. This refrigerant lowers the temperature by turning the liquid to gas

• Once the process continues, the blower pushes warm air across the coil as the refrigerant absorbs the heat and turns to vapor.

•The vapor is then travelled to the compressor that pressurizes and moves it through the condenser coil as the heat is expelled outside.

•After the process, the refrigerant moves through an expansion device that converts it to a low-pressure cool liquid which then reversed to the evaporator coil.

•The above cycle repeats to make the indoor area cooler

Here we have given the brief explanation of split air conditioner working and you may now understand the functionality of it.

Split AC Tonnage and Star Rating Details

When it comes to air conditioning system, it is differentiated by tonnage and star ratings. Let’s have a brief discussion about the Split ac tonnage and star ratings.

Split AC Tonnage details:

A “ton” refers to the heat capacity of a ton of melting ice in a single day. So, there are different tonnage of AC systems such as window AC 1 ton, window Ac 1.5 ton and others. While choosing the tonnage of your AC, you should calculate the size of the room and others to find the apt solution accordingly.

Split AC Star Rating Details:

A star rating in an air conditioner represents the energy efficiency of the appliances. The star ratings are provided by the Bureau of Energy Efficiency (BEE) India from 1 to 5 for the customer’s awareness. However, the initial cost of Split Ac 1 ton 5 star will be higher than Split AC 1 ton with lower or without star ratings. Keeping aside the initial cost, the higher star rating of Split AC 1 ton or 1.5 ton will offer you efficient cooling in quick succession with the lesser life-cycle cost.

Benefits of Using a Split AC Conditioner

To help you figure out what is the best AC system that suits your needs, we have mentioned the benefits of a Split air conditioner unit for your reference.

Various ranges in affordable Costs: Being whatever the product may be, first and foremost a customer will look into the pricing. Compared to other types of Ac system, the Split ACs have many variants available to choose from such as star rating, inverter based, non inverter type, etc.

Available with Multiple Brands: There are dozens of manufacturers for you to choose from which differ in quality, pricing and other aspects. So, there will be plenty of brands for you to choose from.

Energy Efficient: Similar to other AC system, Split ACs is quite energy efficient. If you are looking to stay cool by spending less, then Split AC will be the best option for you.

Easy Installation: The split ac parts are to be mounted at specific and appropriate locations which should be chosen to gain the optimum performance of the AC unit, hence a skilled and experienced team is needed to assess the proposed place for the installation of a Split AC unit.

No Floor Space Required: This type of Ac is designed to fit on a wall, so it doesn’t require any square footage in your room.

Dealers of Split AC in Pune

By referring to all the details mentioned above, you can understand more about a split air conditioning system. If you are looking to install a Split AC in your home, you should definitely need to look out for a trusted partner to make the process comfortable. “Maharashtra Sales and Services” is the leading dealer of Split AC units in Pune and we offer sales, service, installation and maintenance works to make air conditioning of your place easy and comfortable.
